Piezo control valves
For fluidic control processes
- Flexible – extremely low electrical power consumption ensures an extraordinary range of possible applications
- Safe – free of self-heating and consequently maintenance-free without additional cooling systems
- Compact – lightweight design ensures high dynamics and resolutions
The most compelling features of our sophisticated piezo technology for medical technology applications are low actuation current, compact lightweight design and extraordinary durability.
The valves’ minimal electric power consumption does not preclude the implementation of advanced solutions. Medical technology always requires precisely measured amounts of air, gases and liquids as well as maximum flexibility and accuracy in terms of flow rate, temperature and pressure.
The use of HOERBIGER piezo valve technology in fluidic control processes of renowned medical technology manufacturers ensures that intensive care patients and premature babies are safely ventilated, blood pressure can be measured exactly, but non-invasively, and operating systems function reliably.
- Extremely low electrical power consumption
- Self-heating free
- High dynamics and resolution
- Does not cause any switching or control noise
- Compact and light weight
- Excellent price/performance ratio
- The P10 valve is an enclosed version of the P9 valve.
- Switch-on energy:
- 28,8 × 10-6 J
- Control voltage:
- 9 - 30 V
- Nominal pressure:
- 1.2 ± 0.05 bar
- Nominal flow rate:
- 2.0 ± 0.5 l/min at -30°C; 0.8 ± 0.3 l/min at +80°C
- Ambient temperature:
- -10 to +60 °C
- Temperature medium:
- -10 to +60 °C
- Protection class P9:
- IP 00
- Protection class P10:
- IP 20
Compared to the P9 and P10 variants, HOERBIGER has significantly increased the flow rate and extended the working pressure range for the P20 valve.
- Extremely low electrical power consumption
- Self-heating free
- Flange connection for fast mounting
- Compatible with microcontrollers
- Compatible with control modules
- Does not cause switching noise
- Compact and light weight
- Excellent price-performance ratio
- Power-up energy:
- 28,8 × 10-6 J
- Control voltage:
- 9 to 30 V
- Working pressure range:
- min 1.5 bar to max. 8 bar
- Nominal pressure:
- 6 bar
- Nominal flow rate:
- > 110 l/min
- Ambient temperature:
- -10 to +60 °C
- Temperature medium:
- -10 to +60 °C
- Protection class:
- IP 54
